APPLICATIONS
• 100G Ethernet
• ITU-T OTU4
• Data Center and LAN
FEATURES
• Compliant with 100Gbase-LR4
• 4 wavelength lanes Mux/Demux design (1295.56 nm, 1300.05 nm, 1304.59 nm, 1309.14 nm)
• Up to 25.8 Gbps Data rate per wavelength
• Up to 10km transmission on SMF
• Electrically hot-pluggable
• Digital Diagnostics Monitoring Interface
• Compliant with QSFP28 MSA with LC connector
• Case operating temperature range:0°C to 70°C
• Power dissipation < 3.5 W
