Operating Wavelength [nm] |
1260 - 1650 |
Fiber Type |
G.657.A1 |
Insertion Loss [dB] |
3.8 |
7.1 |
10.3 |
13.5 |
16.5 |
20.5 |
Loss Uniformity [dB] |
0.4 |
0.6 |
0.8 |
1.2 |
1.5 |
2.0 |
Polarization Dependent Loss [dB] |
0.2 |
0.2 |
0.2 |
0.3 |
0.3 |
0.4 |
Return Loss [dB] |
50 |
50 |
50 |
50 |
50 |
50 |
Directivity [dB] |
55 |
55 |
55 |
55 |
55 |
55 |
Wavelength Dependent Loss [dB] |
0.5 |
0.5 |
0.5 |
0.5 |
1.0 |
1.0 |
Temperature Stability (-40~85°C) [dB] |
0.5 |
0.5 |
0.5 |
0.5 |
1.0 |
0.5 |
Operating Temperature [°C] |
-40 to +85 |
Storage Temperature [°C] |
-40 to +85 |
Device Dimensions [mm] med 900µm fiber |
4×7x60 |
4x7x60 |
4x7x60 |
4x12x60 |
6x20x80 |
8x40x100 |
Device Dimension [mm] med 250µm fiber | 4x4x40 | 4x4x40 | 4x4x40 | 4x7x50 | 4x7x50 | 4x12x60 |
