APPLICATIONS
• 100GBASE-4WDM
• Data Center
FEATURES
• Up to 80 km transmission on one singlemode fiber
• Hot-Pluggable QSFP footprint
• Simplex LC interface for single fiber operation
• QSFP28 MSA compatible
• LWDM wavelengths: Tx: 1273.54nm (L2), 1277.89nm (L3), 1282.26nm (L4), 1286.66nm (L5), Rx: 1295.56nm (L7), 1300.05nm (L8), 1304.58nm (L9), 1309.14nm (L10)
• Digital Diagnostic monitoring interface
• Operating Case Temperature: Standard: 0°C to 70°C
• Power dissipation < 5.5 W
