SFP+, 10GBase-LR, DDM, 40km DWDM 100GHz C-band, 15dB, I-Temp

SFP+, 10GBase-LR, DDM, 40km

DWDM 100GHz C-band, 15dB, I-Temp

BeskrivelseTeknisk infoTilbehørAlternativer
Beskrivelse

APPLICATIONS
• 10G Ethernet
• 10G Fibre Channel
• Sonet/OC-192 & SDH/STM-64
• DWDM Networks

FEATURES
• 40 km transmission at DWDM

• 15 dB link budget
• Hot-Pluggable SFP+ footprint LC Optical Transceiver
• Small Form-Factor Pluggable + (SFP+) MSA compatible
• 40 DWDM channels (?): 1530.33 nm to 1560.61 nm
• SFF-8472 Digital Diagnostics Monitoring
• Single 3.3 V Power
• Temperature-stabilized DWDM EML laser transmitter
• 100Ghz ITU Grid, C-Band
• Operating temperature -40°C to +85°C



Teknisk info

Produktinformasjon

Formfaktor SFP+
Protokoll / bitrate
  • 10 Gigabit Ethernet
  • 10G Fibre Channel
  • SDH STM-64
  • OTN/G.709/G.sup43 OTU2(e)
Mediatype Singelmodus
Rekkevidde (dB) 15
Rekkevidde (km) 40
Bølgelengde (nm) DWDM
DDM Ja
Konnektor LC Duplex
Produktklassifisering/tollkoder
  • ECCN: 5A991
  • HS: 8517.62.0090
