APPLICATIONS
• IEEE 802.3ae 10GBASE-LR 10.3125 Gb/s
• 10GFC Rev.4.0 1200-SM-LL-L 10.5128 Gb/s
• SDH/SONET ITU-T G.691, ITU-T G.709
FEATURES
• Power Consumption max. 1.5 W
• Compatible with XFP MSA Rev. 4.5
• Compliant to IEEE 802.3ae 10GBASE-LR at 10.3125 Gbit/s
• Conforms with Fibre Channel 1200-SM-LL-L at 10.51875 Gbit/s
• Up to 10 km transmission on 9/125 µm SMF G.652
• Hot pluggable 30 pin connector
• 1310 nm laser
• Duplex LC-connector interface
• Compliant with the EU RoHS 6 Environmental Requirements
