Fiberworks 18 ch. CWDM Mux+Demux C27-C61, Monitor ports, LC/APC Fiberworks 18 ch. CWDM Mux+Demux C27-C61, Monitor ports, LC/APC Fiberworks 18 ch. CWDM Mux+Demux C27-C61, Monitor ports, LC/APC Fiberworks 18 ch. CWDM Mux+Demux C27-C61, Monitor ports, LC/APC

Fiberworks 18 ch. CWDM Mux+Demux

C27-C61, Monitor ports, LC/APC

Varenr: F-CMUX-18-2761-MLA
Datablad / mer produktinformasjon
BeskrivelseTeknisk infoTilbehørAlternativer
Beskrivelse
FEATURES
- Coarse WDM in compliance with ITU-T G.694.2
- All 18 CWDM channels 1270nm - 1610nm with 20nm spacing
- Two 2% monitor ports for easy troubleshooting
- Based on thin film optics with epoxy free optical path
- Protocol transparent (support 1G, 10G etc.)
- 1U in 19" rack
- LC/APC connectors

Teknisk info

Produktinformasjon

Formfaktor 19" 1U
Fibertype SM
Linjefiber Dobbel (fiberpar, mux+demux)
Antall kanaler 18
Add/drop-muligheter Nei, kun mux/demux
Konnektortype Vinklet (APC)
Konnektor LC/APC
Andre egenskaper Monitorport
Produktklassifisering/tollkoder
  • ECCN: EAR99
  • HS: 8517.62.0090
